| Property | Value |
|---|---|
| Item | UPS System |
| UPS Type | Online/Double Conversion |
| Power Rating | 3000VA |
| Mounting | Rack/Tower |
| Wattage | 3000 W |
| Input Voltage | 208V |
| Output Voltage | 208V |
| Backup Time (Half/Full Load) | 11 min/4 min |
| Number of Outlets | 3 |
| Width | 23.8 in |
| Housing Color | Black, Silver |
| Battery Type | Sealed, lead-acid |
| NEMA Receptacle Configuration | (2) L6-20R; (1) L6-30R |
| Noise level | u003c47 dB at 1 meter |
| Certifications | cULus Listed |
| Compliances | IEC 62040-2 Class B Cat C2 |
| Input Frequency Range | 60 Hz: 50 to 70 Hz, 50 Hz: 40 to 60 Hz |
| Input connection | L6-20P |
| Product Height | 3.4 in |
| BTU Rating | Online: 513, Battery: 741 |
| Internal bypass | Yes |
| Output Waveform | True sine wave |
| Product Length/Depth | 23.8 in |
| Rack size | 2U |
| User interface | Graphical display, 5-button programmable menu |
| Form factor | Rack/tower |
| Expansion Slots | (1) Mini-Slot (MS) expansion port. The following optional connectivity cards may be ordered separately.|Gigabit Network Card part number: NETWORK-M2|Modbus card part number: MODBUS-MS|Relay card part number: RELAY-MS |
| Input Cord Length | 6 ft detachable |
| Efficiency | 0.93 |
| Output Power Factor | 1 |
| Relative Humidity | 0-96% non-condensing |
| Input Power Factor | u003e0.99 typical |
| Battery replacement | Hot-swappable internal batteries and extended battery modules (EBMs) |
| Extended Battery Capability | Add up to 4 extended battery modules (EBM). Part number 9PXEBM72RT |
| Receptacle | (2) L6-20R, (1) L6-30R |
| VA rating | 3000 VA |
| Communication | MiniSlot + 1 USB port + 1 serial RS232 port + 1 mini-terminal block for remote ON/OFF + 1 mini-terminal block for remote power off + 1 mini-terminal block for output relay Communication slot |
| Altitude | 0-1500m (0° to 40°C), 1500-3000m (0° to 35°C) |
| Temperature range | 0° to 40°C (32° to 104°F) |
| Software Compatibility | Intelligent Power Software Suite |
| Rack Mounting Kit | Yes |
| Battery management | ABM technology (3-stage charging extends battery service life by 50% and provides advance warning for battery replacement) |
| Package Contents | 9PX3000GLRT UPS|Input cable|4-post rail kit|Safety manual|User manual|Tower pedestals|RS-232 serial cable|USB cable|Intelligent Power Software Suite CD |
| Country of Origin (subject to change) | Unknown |
| Package Quantity | 1 |
UPS System, 3000VA, 3 Outlets, Rack/Tower, Out: 208V , In:208V, Eaton, Mfr#: 9PX3000GLRT
$4239.99
Free shipping will be applied on orders over $50
Out of stock
