| Property | Value |
|---|---|
| Overall Height | 47 1/2 in |
| Overall Length | 40 5/8 in |
| Overall Width | 20 1/2 in |
| Color | Yellow |
| Load Capacity | 5,000 lb |
| Item | Pallet Jack |
| Handle Type | Round Tear Drop |
| Assembled | Yes |
| Frame Material | Steel |
| Load Wheel/Tread Material | Polyurethane |
| Fork Style | Narrow |
| Load Wheel Diameter | 2 7/8 in |
| Operation | Manual |
| Width Between Forks | 8 in |
| Handle Material | Plastic, Steel |
| Steering Arc | 90 Degrees |
| Frame Finish | Powder Coated |
| Fork Length | 36 in |
| Fork Type | Fixed |
| Grease Fittings | 3 exterl |
| Width Across Forks | 20 1/2 in |
| Features | Handgrip, Power-Start Technology |
| Handle Height | 47 1/2 in |
| Steer Wheel Diameter | 7 in |
| Weight | 163 lb |
| Wheel Base | 34 in |
| Fork Width | 6 1/4 in |
| Fluid Type | ISO 150, 8W32 |
| Number of Batteries | 0 |
| Minimum Lifting Height | 7/8 in |
| Steer Wheel/Tread Material | Polyurethane |
| Maximum Incline | 10 Degrees |
| Fork Thickness | 2 7/8 in |
| Overall LxWxH | 40 5/8 in x 21 in x 48 in |
| Maximum Lifting Height | 7 3/4 in |
| Axle Dia. | 5/8 in |
| For Pallet Type | Open/Closed |
| Turning Radius | 4 ft |
| Steer Wheel Width | 2 1/4 in |
| Load Wheel Width | 3 3/4 in |
| Load Wheel Bearing Type | Ball Bearing |
| Maximum Decline | 10 Degrees |
| Steer Wheel Bearing Type | Ball Bearing |
| Lifting Height per Pump | 1/8 in |
| Strokes To Maximum Lift Height | 40 |
| Steer Wheel Axle Diameter | 5/8 in |
| For Surface Type | Brick, Carpet, Concrete, Wood |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
Pallet Jack, 36 in Fork Length, Fixed Fork, LIFT-RITE, Mfr# ST23LY9F-00P
$1704.99
Free shipping will be applied on orders over $50
5,000 lb, Fork Style Narrow, Fork Type Fixed, Fork Length 36 in, Fork Width 6 1/4 in, Width Across Forks 20 1/2 in, Width Between Forks 8 in, Overall Length 40 5/8 in, Overall Width 20 1/2 in, Overall Height 47 1/2 in, Frame Material Steel, Minimum Lifting Height 7/8 in, Maximum Lifting Height 7 3/4 in, Fork LxW 36 in x 20 1/2 in, Overall LxWxH 40 5/8 in x 21 in x 48 in
Out of stock
