| Property | Value |
|---|---|
| Item | Single-Phase Basic PDU |
| Number of Outlets | 13 |
| Voltage | 120VAC |
| Color | Black |
| Cord Length | 4.57m |
| Max. Amps | 15A |
| Mounting Style | Vertical Rackmount/0U |
| Power Indicator | No |
| Housing Material | Metal |
| NEMA Receptacle Configuration | NEMA 5-15R |
| NEMA Plug Configuration | NEMA 5-15P |
| Length | 4 1/2 in |
| Outlet Center Distance | 30.2mm |
| GFCI Protected | No |
| Plug Type | NEMA 5-15P |
| Phase | Single |
| Outlet Surge Protection | No |
| Height | 1 3/4 in |
| Includes | Mounting Hardware |
| Receptacle Type | NEMA 5-15R |
| Special Features | Detachable Mounting Flanges |
| Circuit Breaker | No |
| Width | 17 1/2 in |
| Metered | Non-Metered |
| Standards | CE, EAC, FCC Part 15 Class A, RoHS Compliant, TAA Compliant |
| Hz | 50/60 Hz |
| Depth | 4.5 |
| Frequency | 50/60 Hz |
| Length (Straight Wireway) | 4 1/2 in |
| Overall Height | 1 3/4 in |
| Overall Width | 17 1/2 in |
| Overall Length | 4 1/2 in |
| Features | Detachable Mounting Flanges |
| Watts | 1.9kW (127V), 1.8kW (120V), 1.5kW (100V) |
| Type | Basic |
| Mount Type | Rack-mountable |
| Mounting Orientation | Horizontal |
| Additional Information | Corded AC power distribution unit with 15 amp capacity and 13 AC receptacles, Versatile all-metal cabinet with detachable mounting flanges allows wallmount, under-counter and 19 inch rackmount mounting in both 1U or zero-U formats, Detachable flanges with pre-punched access holes and adjustable depth channels allow user configuration in dozens of potential mounting schemes, including zero-U rackmount capability in the cable management area or other available space within a rack enclosure, Unfiltered electrical pass-through reliably distributes alternate waveform AC power from UPS or generator to supported equipment, 13 NEMA5-15R output receptacles accept common NEMA5-15 equipment plugs, 15 foot AC cord NEMA5-15P plug connection, Switch-free design prevents the potential for accidental shutoff of connected loads, 15 amp electrical capacity with circuit breaker, 120V AC, 50/60Hz electrical compatibility |
| Package Contents | PDU1215 PDU Basic 120V 15A 13 Outlet, PDU1215 Rackmount Power Strip, Warranty information, Instruction manual |
| Power Rating (Watt) | 1800 W |
| Certifications u0026 Standards | cUL, UR |
| Plug/Connector Detail | 1 x NEMA 5-15P |
| Network (RJ-45) | Yes |
| Rack Height | 1U |
| Output Voltage | 120 V AC |
| PDU Type | Basic |
| Compatibility | TYPICAL APPLICATIONS: Multi-outlet power distribution unit is the ideal means of powering multiple loads in 19 inch rackmount, wallmount and under-counter applications, such as internetworking, PC systems, telecommunications, audio/video, security, sound reinforcement and more. Ideal for distribution of UPS, generator or commercially derived AC power to protected equipment. |
| Product Name | PDU1215 PDU Basic 120V 15A 13 Outlet |
| Input Current | 15 A |
| Receptacle Detail | 13 x NEMA 5-15R |
| Input Voltage | 120 V AC |
| Maximum Operating Temperature | 104 Degrees F |
| Maximum Current | 15 A |
| Manufacturers Warranty Length | 5 yr |
| Maximum Output Voltage | 120V AC |
| Built-In Circuit Breaker | Yes |
| Minimum Operating Temperature | 32 Degrees F |
| Maximum Input Voltage | 120V AC |
| Rack Units | Not Applicable |
| Frequency Compatibility | 50 / 60 Hz |
| PDU Form Factor | Horizontal (1U) |
| Relative Humidity | 5% to 95% non-condensing |
| Material of Construction | Metal |
| Outlets Measurement (Center to Center) | 30.2mm |
| Overload Protection | 15A Breaker |
| Maximum Input Amps | 15 |
| Input Phase | Single-Phase |
| PDU Input Voltage | 120 |
| Switches | No power switch |
| Minimum Required Rack Depth (inches) | 7.5 |
| Output Capacity (kW) | 1.8 |
| Unit Dimensions (hwd / in.) | 2.000 x 20.000 x 4.500 |
| Input Cord Length (ft.) | 15 |
| Package Includes | PDU1215 1.8kW Single-Phase 120V Basic PDU;Mounting hardware;Owner's manual |
| Grounding | Grounding lug |
| Operating Temperature Range | 32° to 104°F (0° to 40°C) |
| Output Receptacles | (13) 5-15R |
| Product Certifications | RETIE (Colombia); CAN/CSA-22.2 No. 308-14 (Canada); NOM (Mexico); UL 1363 |
| Form Factors Supported | 1U rackmount, 0U vertical rackmount, wall-mount and undercounter installation supported |
| Output Capacity Details | 1.8kW (120V) / 15A total capacity; 12A max per 5-15R outlet |
| Storage Temperature Range | -22° to 122°F (-30° to 50°C) |
| Output Nominal Voltage | 120V |
| PDU Plug Type | NEMA 5-15P |
| Recommended Electrical Service | Single-phase 15A 120V service |
| Operating Elevation (ft.) | 0-10,000 |
| Country of Origin (subject to change) | China |
| Package Quantity | 1 |
PDU, 15A, 13 Outlet, 15 ft, Black, Tripp Lite, Mfr#: PDU1215
$119.99
Free shipping will be applied on orders over $50
Power Distribution Unit, Built-In Circuit Breaker Yes, Color Black, Cord Length 15 ft, Number of Outlets 13, Receptacle Type NEMA 5-15R, Maximum Input Voltage 120V AC, Outlet Surge Protection No, Metered Non-Metered, Rack Units Not Applicable, Mounting Location Vertical Rack, Plug Type NEMA 5-15P, Features Detachable Mounting Flanges, Housing Material Metal, Includes Mounting Hardware, Manufacturers Warranty Length 5 yr, Maximum Current 15 A, Maximum Operating Temperature 104 Degrees F
Out of stock
