| Property | Value |
|---|---|
| Item | Noncontact Ultrasonic Level Sensor |
| Connection Size | 1 1/2 in |
| Connection Type | NPT |
| Standards | CE Certified, cTUVus, FCC, RoHS |
| Width | 3.9 in |
| Mounting | 1-1/2 in NPT |
| Gasket Material | Silicone |
| Output | 4 to 20mA, 2-Wire |
| Accuracy | +/-3 mm |
| Input Voltage | 16 to 26V DC |
| Display Type | LCD |
| Enclosure Rating | IP67 |
| Overall Height | 12.2 in |
| Voltage - Maximum | 26V DC |
| Operating Frequency | 26 kHz |
| Overall Diameter | 3 3/4 in |
| Spatial Resolution | 0.118 in |
| Output Voltage Range | 4 to 20mA |
| Output Wire Configuration | 2-Wire |
| Enclosure Material | Aluminum |
| Media Temperature - Minimum | -76 Degrees F |
| Operating Pressure - Maximum | 72 psi |
| Antenna Diameter | 3 7/8 in |
| Dead Band | 12 in |
| Range | 1,180.8 in |
| For Media Type | Chemicals, Oil, Wastewater, Water |
| Overall Width | 3.9 in |
| Beam Angle | 8 Degrees |
| Media Temperature - Maximum | 302 Degrees F |
| Country of Origin (subject to change) | China |
| Package Quantity | 1 |
Noncontact Ultrasonic Level Sensor, 3.9"W, FLOWLINE, Mfr# LR15-0010-40
$2600
Free shipping will be applied on orders over $50
Noncontact Ultrasonic Level Sensor, For Media Type Chemicals, Oil, Wastewater, Water, Antenna Diameter 3 7/8 in, Range 1,180.8 in, Connection Size 1 1/2 in, Connection Type NPT, Accuracy +/-3 mm, Voltage - Maximum 26V DC, Dead Band 12 in, Beam Angle 8 Degrees , Operating Frequency 26 kHz, Spatial Resolution 0.118 in, Operating Pressure - Maximum 72 psi, Media Temperature - Minimum -76 Degrees F, Media Temperature - Maximum 302 Degrees F, Output Wire Configuration 2-Wire
Out of stock
