| Property | Value |
|---|---|
| Item | Molded Case Circuit Breaker |
| Amps | 110 A |
| AC Voltage Rating | 480V AC |
| DC Voltage Rating | Not Rated |
| Max. AIR Rating | 42kA at 480V AC |
| Terminal Connection | Load Side Lug |
| Series | HED4 |
| Number of Poles | 3 |
| Circuit Breaker Actuator | Toggle |
| Frame Size | 125A/ED |
| Circuit Breaker Mounting Style | Lug In Panelboard |
| Circuit Breaker Type | Standard |
| Standards | HACR Rated, UL Listed |
| Instantaneous Trip | Fixed |
| Depth | 4 in |
| Mounting | Lug In Panelboard |
| Min. Wire Size | 1/0 AWG (Al), 3 AWG (Cu) |
| For Use With | SB Switchboards, Sentron Panelboards |
| High Amp Trip Setting | 110 A |
| Width | 3 in |
| Height | 6.34 in |
| Phase | Three |
| Max. Wire Size | 2 AWG (Al), 3 AWG (Cu) |
| Low Amp Trip Setting | 110 A |
| Phase Connection | ABC |
| Trip Type | Thermal Magnetic |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
Molded Case Circuit Breaker, 110 A, 480V AC, 3 Pole, Lug In Panelboard Mounting Style, HED4 Series, SIEMENS, Mfr# HED43B110
$5288.99
Free shipping will be applied on orders over $50
Molded Case Circuit Breaker, 110 A Amps, AC Voltage Rating 480V AC, Max. AIR Rating 42kA at 480V AC, For Use With SB Switchboards, Sentron Panelboards, Series HED4, High Amp Trip Setting 110 A, Low Amp Trip Setting 110 A, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating Not Rated, Terminal Connection Load Side Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC, Frame Size 125A/ED, Circuit Breaker Mounting Style Lug In Panelboard
Out of stock
