| Property | Value |
|---|---|
| Item | Indexable Profiling End Mill |
| Series | M370 |
| Overall Length | 50.00mm |
| Depth of Cut | 2.00mm |
| Material - Machining | High Speed Steel |
| Cutting Direction | Right Hand |
| Insert Size | 120713 |
| Rake | -11 Degrees Axial, 9 Degrees Radial |
| Features | Double-Sided, First Choice for Roughing Applications, High Metal Removal Rates, Six Cutting Edges |
| Insert Holding Type | Screw |
| Insert Style | WOEJ R |
| Compatible Hardware | Coolant Screw Assembly M16, Insert Screw M4x0.7 x 11.5 IP15, Torx Plus Drive Wrench DT15IP |
| Coolant Fed | Coolant Through |
| ISO Number | M370D100Z07WO12 |
| Max. Speed | 13,810 RPM |
| Max. Cutting Dia. | 100.00mm |
| Number of Inserts | 7 |
| ANSI Code | M370D100Z07WO12 |
| Cutting Application | 3D Profiling, Face Milling, Helical Milling, Plunge Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Roughing, Slotting: Square End |
| Arbor Dia. | 32.00mm |
| Hub Outside Dia. | 78.00mm |
| Country of Origin (subject to change) | Germany |
| Package Quantity | 1 |
Indexable Face Mill, M370 Series, High Speed Steel, 2.00mm Depth of Cut, Widia, Mfr#: M370D100Z07WO12
$980.99
Free shipping will be applied on orders over $50
Indexable Profiling End Mill, Max. Cutting Dia. 100.00mm, Depth of Cut 2.00mm, Overall Length 50.00mm, ANSI Code M370D100Z07WO12, Compatible Hardware Coolant Screw Assembly M16, Insert Screw M4x0.7 x 11.5 IP15, Torx Plus Drive Wrench DT15IP, Coolant Fed Coolant Through, Cutting Application 3D Profiling, Face Milling, Helical Milling, Plunge Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Roughing, Slotting: Square End
Out of stock
