| Property | Value |
|---|---|
| Drill Bit Grouping | Drill Bit |
| Item | Jobber Length Drill Bit |
| Drill Bit Dimension Type | Letter |
| Drill Bit Size | I |
| Shank Type | Straight |
| Drill Bit Point Angle | 135 Degrees |
| Drill Bit Material | Cobalt |
| Drill Bit Finish | Black/Gold |
| Decimal Equivalent | 0.2720 |
| Flute Type | Spiral |
| Material | Cobalt |
| Coolant Fed | Non-Coolant Through |
| Shank Dia. | 17/64 in |
| Overall Length | 4-1/8 in |
| Cutting Direction | Right Hand |
| Number of Flutes | 2 |
| Flute Length | 2-7/8 in |
| Maximum Drilling Depth | 2 5/32 in |
| Primary Material Application | Steel, Cast Iron, Aluminum and Non-Ferrous Material, Hi-Temp Alloy, Hardened Steel |
| Depth:Dia. Ratio | 4xD |
| Drill Bit Point Type | Split Point |
| Helix Angle | 21 Degrees to 34 Degrees |
| Material Grade - Machining | High Performance |
| Shank Length | 1-1/4 in |
| Point type | Split Point |
| Shank Type - Machining | Straight |
| Application | For Alloy, Stainless Steel, Titanium, Manganese Steel, Armor Plate |
| List Number | 1802 |
| Standards | ASME B94.11M |
| Series | 1802 |
| Drill Diameter Tolerance | +0.0000 in/-0.0010 in |
| Grade | Heavy Duty |
| Spiral Direction | Right Hand |
| Primary Material Application ISO Code | H, K, N, P, S |
| Material - Machining | Cobalt |
| Depth x Dia. Ratio | 4xD |
| Drill Point Length | 0.0000 in |
| Drill Length Class | Jobber Length |
| Measurement System | Letter |
| Coolant Through | No |
| Finish - Machining | Straw/Bronze |
| Web Thinning | Thinned |
| Sheeter Drill | No |
| Number of Coolant Holes | 0 |
| Aircraft Drill | No |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
I Cobalt 135 Deg. Jobber Length Drill Bit, CLE-LINE, Mfr# C23327
$6.19
Free shipping will be applied on orders over $50
Jobber Length Drill Bit, Drill Bit Size I, Drill Bit Point Angle 135 Degrees , Cobalt, Straw/Bronze, Decimal Equivalent 0.2720, Letter, Drill Bit Point Type Split Point, Non-Coolant Through, Number of Coolant Holes 0
Out of stock
