| Property | Value |
|---|---|
| Voltage | 115V AC |
| Application | Designed for Gasoline, Diesel, Biodiesel Up to B20, E15, Kerosene and Mineral Spirit |
| HP | 1/3 |
| Housing Material | Cast Iron |
| GPM | 20 gpm |
| Inlet Size | 1-1/4 in MNPT |
| Seal Material | Carbon |
| RPM | 1725 |
| Pump Design | Rotary Vane |
| Self-Priming | Yes |
| Seal Type | O-ring |
| Max. Viscosity | 34.3 SUS |
| Item | Fuel Transfer Pump |
| Pressure Range | 0 psi to 23 psi |
| Duty Cycle | 30 Minutes On/30 Minutes Off |
| Transfer Pump Application | Agriculture, Construction, Farming |
| Standards | UL/cUL |
| Hose Length | 12 ft |
| Features | Explosion Proof Motor, Thermal Overload Protection |
| Manufacturers Warranty Length | 2 yr |
| Bearing Type | Permanently Lubricated Ball |
| Nozzle Material | Aluminum |
| Overall Height | 10 in |
| Bypass Valve | Internal |
| Outlet Size | 3/4 in FNPT |
| Overall Width | 11 1/2 in |
| Amps AC | 5.5 |
| Overall Length | 14 1/2 in |
| Hose Dia. | 3/4 in |
| Compatible Fluids | Biodiesel up to B20, Diesel, E15, Gasoline, Kerosene |
| Metered | No |
| Includes | Hose, Installation Components, Nozzle |
| Nozzle Type | Manual |
| Motor Enclosure | Explosion Proof |
| Motor Type | Permanent Magnet |
| Agency Compliance | cULus |
| Motor RPM | 1,725 RPM |
| Housing Material - Pumps | Cast Iron |
| Includes Nozzle | Yes |
| Power Source | Electric |
| Max. Flow Rate | 20 gpm |
| Nozzle Operation | Manual |
| Pump Connection Type | NPT |
| Hose Outside Dia. | 3/4 in |
| Compatible Chemicals | Biodiesel, Diesel, E15, Gasoline, Kerosene |
| Discharge Connection Type | NPT |
| Full Load Amps | 5.5 A |
| Motor HP | 1/3 hp |
| Nozzle Fluid Compatibility | Diesel |
| Mount Type | Bung |
| For Media Type | Biodiesel, Diesel, E15, Gasoline, Kerosene |
| Rated Voltage | 115V AC |
| Max. Outlet Pressure | 23 psi |
| For Container Size | 5,000 gal |
| Explosion Proof | Yes |
| Meter Unit Of Measure | Not Applicable |
| Includes Discharge Hose | Yes |
| Meter Type | Not Applicable |
| Max. Head Pressure | 23 psi |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
Fuel Transfer Pump, 115V AC, 20 gpm Max. Flow Rate , 1/3 HP, Cast Iron, 1-1/4 in MNPT Inlet, Fill-Rite, Mfr#: FR700V
$739.99
Free shipping will be applied on orders over $50
The Fill-Rite FR700V Fuel Transfer Pump is a versatile tool that can be used to transfer gasoline, diesel, biodiesel up to B20, E15, kerosene and mineral spirit. Designed for heavy duty use in the agriculture, construction and farming industries. With a thermal overload protection system, you can work with confidence knowing that this pump will keep going even under extreme conditions. The explosion proof motor ensures your safety when working with flammable liquids. This fuel transfer pump has an inlet size of 1 1/4" MNPT and an outlet size of 3/4" FNPT. Equip yourself with the Fill-Rite FR700V Fuel Transfer Pump so you are ready for any job on the farm or worksite.
Out of stock
