| Property | Value |
|---|---|
| Item - Data Cable | Fiber Optic Patch Cord |
| Fiber Optic Connector Type | LC/SC |
| Simplex/Duplex/Multifiber | Duplex |
| Attenuation | 3.0 dB/km @ 850 Nanometers |
| Core Dimension - Fiber Optic Cable | 62.5 Micrometer |
| Fire Rating - Data Cable | Riser |
| Length - Patch Cord | 3.0 m |
| Jacket Color | Orange |
| Fiber Count - Fiber Optic Cable | 2 |
| Item | Fiber Optic Patch Cord |
| Single Mode/Multi-Mode | Multi-Mode |
| Connector Type - Patch Cord | LC, SC |
| Color | Orange |
| Jacket Material - Wire and Cable | PVC |
| NEC Article and Type | OFNR |
| Standards | FDDI, REACH, RoHS Compliant |
| Length | 3m |
| Construction | Zipcord Fiber |
| Core Dimension | 62.5 Micrometer |
| Fiber Count | 2 |
| Jacket Type | PVC |
| Clad Dimension | 125 micron |
| Bandwidth | 1 GBps, 10 GBps |
| Overall Length | 9.8 ft |
| Cable Length | 10 ft |
| Approvals | FDDI and OFNR rated |
| Optical Mode | OM1 |
| Technology | Multimode |
| Side B - Connector 1 | SC DUPLEX (MALE) |
| Number of Fibers | Duplex |
| Cable Length (ft.) | 9.8 |
| Cable Length (in.) | 118.1 |
| Side A - Connector 1 | LC DUPLEX (MALE) |
| Clad Diameter | 125 micron |
| Core Diameter | 62.5 micron |
| Network Speed | 1Gbps |
| Cable Type | Fiber Optic |
| Additional Information | Fiber made from glass (not a polymer), Color coded shrouds identify transmit and receive |
| Package Contents | Duplex Fiber Optic Patch Cable, 3M Duplex MMF Cable LC/SC 62.5/125 Fiber |
| Certifications u0026 Standards | FDDI |
| Jacket Material | PVC |
| Connector on Second End Details | 2 x SC Network - Male |
| Cable Characteristic | Patch Cable |
| Product Type | Network Cable |
| Connector on First End Details | 2 x LC - Male |
| Product Name | Duplex Fiber Optic Patch Cable |
| End 1 Connection Type | LC |
| Mode | Multi-Mode |
| Fiber Material | Glass |
| Maximum Distance | 3.0dB/km @ 800nm |
| End 2 Connection Type | SC |
| Fire Rating | Riser |
| Clad Diameter (microns) | 125 |
| Operating Temperature Range | -4° to 140°F (-20° to 60°C) |
| Minimum Bend Radius | 20 mm (Dynamic), 10 mm (Static) |
| Cable Jacket Color | Orange |
| Storage Humidity Range | 35% to 65% RH, Non-Condensing |
| Endface Polish | PC |
| Package Includes | 3M Duplex MMF Cable LC/SC 62.5/125 Fiber |
| Operating Humidity Range | 5% to 85% RH, Non-Condensing |
| Connector Color | White, Beige |
| Fiber Cable Length | 3M (9.8 ft) |
| Storage Temperature Range | -4° to 140°F (-20° to 60°C) |
| Attenuation @ 850NM | 3.0 dB/km |
| Insertion Loss | LC ? 0.20 dB, SC ? 0.20 dB |
| Core Diameter (microns) | 62.5 |
| Network Compatibility | 1 Gbps (Gigabit), 10 Gbps |
| Cable Jacket Material | LSZH |
| Cable Jacket Rating | OFNR |
| Country of Origin (subject to change) | China |
| Package Quantity | 1 |
Fiber Optic Patch Cord, LC/SC, 3m, Orange, TRIPP LITE, Mfr# N316-03M
$14.49
Free shipping will be applied on orders over $50
Fiber Optic Patch Cord, Mode Multi-Mode, End 1 Connection Type LC, End 2 Connection Type SC, Jacket Color Orange, Overall Length 9.8 ft, Jacket Material PVC, Clad Dimension 125 micron, Core Diameter 62.5 micron, Fiber Count 2, Number of Fibers Duplex, Fire Rating Riser, Attenuation 3.0 dB/km @ 850 Nanometers, Bandwidth 1 GBps, 10 GBps, Fiber Material Glass, Maximum Distance 3.0dB/km @ 800nm, NEC Article and Type OFNR, Standards FDDI, REACH, RoHS Compliant
Out of stock
