| Property | Value |
|---|---|
| Dimension Type | Decimal inch |
| Overall Length | 4 1/2 in |
| Milling Diameter | 3/4 |
| End Mill Material | High Speed Steel |
| Shank Dia. | 3/4 in |
| Number of Flutes | 3 |
| Length of Cut | 2 1/4 in |
| Single End/Double End | Single End |
| End Mill Cutting Type | Center Cutting |
| Helix Angle | 30 Degrees |
| Cutting Direction | Right Hand |
| Pitch | Chamfered Pitch |
| Neck Length | 0 in |
| List Number | 6A0R |
| End Mill Application | Roughing |
| Stainless (M) Compatibility | No |
| Hardened (H) Compatibility | No |
| End Mill Style | Corner Chamfer |
| Finish | Ticn |
| Steel (P) Compatibility | No |
| Super Alloy (S) Compatibility | No |
| Shank Type | Weldon |
| Item | Corner Chamfer End Mill |
| Grade | 0 |
| Non Ferrous (N) Compatibility | Yes |
| Cast Iron (K) Compatibility | No |
| Milling Dia. | 3/4 in |
| Chamfer Width | 0.0140 in |
| Measurement System | Fractional Inch |
| Material - Machining | High Speed Steel |
| Finish - Machining | TiCN |
| Shank Type - Machining | Weldon Flat |
| Drilling Tool Configuration | Individual |
| Coolant Fed | Non-Coolant Through |
| Primary Material Application | Aluminum, Brass, Bronze, Copper, Magnesium |
| Spiral Direction | Right Hand |
| Country of Origin (subject to change) | Israel |
| Package Quantity | 1 |
End Mill, TiCN, 0.7500 in Milling Dia, 6A0R, Widia, Mfr#: TC6A3R19007
$114.99
Free shipping will be applied on orders over $50
Corner Chamfer End Mill, 3/4 in Milling Dia., High Speed Steel, Non-Coolant Through, Weldon Flat, Fractional Inch, 0.0140 in, 2 1/4 in
Out of stock
