| Property | Value |
|---|---|
| Dimension Type | Metric |
| Milling Diameter | 20.00mm |
| End Mill Material | Carbide |
| Number of Flutes | 3 |
| Length of Cut | 24.00 mm |
| Single End/Double End | Single End |
| End Mill Cutting Type | Center Cutting |
| Grade | Bright (Uncoated) |
| Shank Dia. | 20.00 mm |
| Overall Length | 104.00 mm |
| Helix Angle | 40 Degrees |
| Corner Radius | 1.00mm |
| Hardened (H) Compatibility | No |
| Item | Corner Radius End Mill |
| List Number | 49N9 |
| Pitch | Chamfered Pitch |
| Stainless (M) Compatibility | No |
| Milling Dia. | 20.00 mm |
| Non Ferrous (N) Compatibility | Yes |
| Cutting Direction | Right Hand |
| End Mill Application | Roughing |
| Cast Iron (K) Compatibility | No |
| End Mill Style | Corner Radius |
| Shank Type | Straight |
| Super Alloy (S) Compatibility | No |
| Finish | Bright (Uncoated) |
| Steel (P) Compatibility | No |
| Neck Length | 36.00mm |
| Material - Machining | Carbide |
| Measurement System | Metric |
| Finish - Machining | Bright (Uncoated) |
| Shank Type - Machining | Straight |
| Material Grade - Machining | Bright (Uncoated) |
| Drilling Tool Configuration | Individual |
| Primary Material Application ISO Code | N |
| Primary Material Application | Aluminum, Brass, Bronze, Copper, Magnesium |
| Coolant Fed | Non-Coolant Through |
| Country of Origin (subject to change) | Israel |
| Package Quantity | 1 |
End Mill, 7.00mm Milling Dia., D003/D013, WIDIA HANITA, Mfr# 49N920007..
$209.99
Free shipping will be applied on orders over $50
Corner Radius End Mill, 20.00 mm Milling Dia., Carbide, Non-Coolant Through, Straight, Metric, 1.00mm, 24.00 mm, 104.00 mm
Out of stock
