| Property | Value |
|---|---|
| Dimension Type | Metric |
| Milling Diameter | 6.00mm |
| End Mill Material | Carbide |
| Number of Flutes | 2 |
| Length of Cut | 13.00 mm |
| Single End/Double End | Single End |
| End Mill Cutting Type | Center Cutting |
| Grade | ALTIN-MT |
| Shank Dia. | 6.00 mm |
| Overall Length | 57.00 mm |
| Milling Dia. | 6.00 mm |
| End Mill Application | Finishing |
| End Mill Style | Corner Radius |
| Steel (P) Compatibility | Yes |
| Cast Iron (K) Compatibility | Yes |
| Helix Angle | 38 Degrees |
| Stainless (M) Compatibility | Yes |
| Neck Length | Not Applicable |
| Item | CR End Mill,0.40mm CR,6.00mm Dia |
| Non Ferrous (N) Compatibility | Yes |
| Corner Radius | 0.40mm |
| Shank Type | Straight |
| List Number | 5777 |
| Cutting Direction | Right Hand |
| Finish | AlTiN |
| Hardened (H) Compatibility | Yes |
| Super Alloy (S) Compatibility | Yes |
| Material - Machining | Carbide |
| Measurement System | Metric |
| Finish - Machining | AlTiN |
| Material Grade - Machining | AlTiN-MT |
| Shank Type - Machining | Straight |
| Drilling Tool Configuration | Individual |
| Primary Material Application ISO Code | K, M, P |
| Primary Material Application | Cast Iron, Stainless Steel, Steel |
| Coolant Fed | Non-Coolant Through |
| Country of Origin (subject to change) | Israel |
| Package Quantity | 1 |
End Mill, 4.50mm Milling Dia., D002/D012, WIDIA HANITA, Mfr# 577706002MT
$49.65
Free shipping will be applied on orders over $50
Corner Radius End Mill, 6.00 mm Milling Dia., Carbide, Non-Coolant Through, Straight, Metric, 0.40mm, 13.00 mm, 57.00 mm
Out of stock
