| Property | Value |
|---|---|
| Dimension Type | Metric |
| Milling Diameter | 8.00mm |
| Overall Length | 63.00 mm |
| End Mill Material | Carbide |
| Shank Dia. | 8.00 mm |
| Number of Flutes | 6 |
| Length of Cut | 16.00 mm |
| Single End/Double End | Single End |
| End Mill Cutting Type | Center Cutting |
| Helix Angle | 45 Degrees |
| Cutting Direction | Right Hand |
| Finish | TiAlN |
| Milling Dia. | 8.00 mm |
| End Mill Style | Corner Chamfer |
| Non Ferrous (N) Compatibility | No |
| Stainless (M) Compatibility | Yes |
| Hardened (H) Compatibility | Yes |
| Shank Type | Straight |
| Cast Iron (K) Compatibility | Yes |
| Item | End Mill,20.00mm Dia,26.00mm Cut,Carbide |
| Steel (P) Compatibility | Yes |
| End Mill Application | Roughing |
| Pitch | Flat Shallow |
| Grade | TIALN-LT |
| Super Alloy (S) Compatibility | Yes |
| List Number | 4970 |
| Neck Length | Not Applicable |
| Chamfer Width | 0.60 mm |
| Finish - Machining | TiAlN |
| Measurement System | Metric |
| Material - Machining | Carbide |
| Shank Type - Machining | Straight |
| Material Grade - Machining | TiAlN-LT |
| Drilling Tool Configuration | Individual |
| Secondary Material Application ISO Code | K, M, P, S |
| Secondary Material Application | Cast Iron, Stainless Steel, Steel, Super Alloy |
| Primary Material Application | Hardened Steel |
| Primary Material Application ISO Code | H |
| Country of Origin (subject to change) | Israel |
| Package Quantity | 1 |
End Mill, 20.00mm Milling Dia., D004/D014, Widia, Mfr#: 497008003LT
$74.55
Free shipping will be applied on orders over $50
Corner Chamfer End Mill, 8.00 mm Milling Dia., Carbide, TiAlN, Straight, Metric, 0.60 mm, 16.00 mm
Out of stock
