| Property | Value |
|---|---|
| Measurement System | Metric |
| Milling Diameter | 3.00mm |
| Overall Length | 54.00 mm |
| Number of Flutes | 4 |
| End Mill Style | Corner Radius |
| Finish | AlTiN |
| Length of Cut | 7.00 mm |
| End Mill Cutting Type | Center Cutting |
| Cast Iron (K) Compatibility | Yes |
| Dimension Type | Metric |
| Pitch | Chip Breaker |
| Neck Length | Not Applicable |
| Steel (P) Compatibility | Yes |
| Stainless (M) Compatibility | Yes |
| End Mill Application | Roughing |
| Grade | WP15PE |
| Shank Dia. | 6.00 mm |
| Helix Angle | 35 Degrees |
| Hardened (H) Compatibility | Yes |
| Milling Dia. | 3.00 mm |
| Cutting Direction | Right Hand |
| Single End/Double End | Single End |
| End Mill Material | Carbide |
| List Number | DQ13 |
| Shank Type | Weldon |
| Super Alloy (S) Compatibility | Yes |
| Non Ferrous (N) Compatibility | No |
| Corner Radius | 0.25mm |
| Item | Corner Radius End Mill |
| Finish - Machining | AlTiN |
| Material - Machining | Carbide |
| Shank Type - Machining | Weldon Flat |
| Material Grade - Machining | WP15PE |
| Drilling Tool Configuration | Individual |
| Primary Material Application | Cast Iron, Steel |
| Primary Material Application ISO Code | K, P |
| Coolant Fed | Non-Coolant Through |
| Country of Origin (subject to change) | Israel |
| Package Quantity | 1 |
End Mill, 12.00mm Milling Dia., 4777, WIDIA HANITA, Mfr# DQ1303002W
$97.45
Free shipping will be applied on orders over $50
Corner Radius End Mill, 3.00 mm Milling Dia., Carbide, Non-Coolant Through, Weldon Flat, Metric, 0.25mm, 7.00 mm, 54.00 mm
Out of stock
