| Property | Value |
|---|---|
| Dimension Type | Decimal inch |
| Milling Diameter | 1 |
| Overall Length | 4 1/2 in |
| Shank Dia. | 1 in |
| End Mill Material | Cobalt |
| Number of Flutes | 6 |
| Length of Cut | 2 in |
| Single End/Double End | Single End |
| End Mill Cutting Type | Center Cutting |
| Helix Angle | 35 Degrees |
| Cutting Direction | Right Hand |
| List Number | 620V |
| Steel (P) Compatibility | Yes |
| End Mill Style | Corner Chamfer |
| Neck Length | 0 in |
| Hardened (H) Compatibility | No |
| Stainless (M) Compatibility | Yes |
| Milling Dia. | 1 in |
| Item | Corner Chamfer End Mill |
| Finish | Bright (Uncoated) |
| Pitch | WavCut II |
| End Mill Application | Roughing |
| Super Alloy (S) Compatibility | Yes |
| Cast Iron (K) Compatibility | No |
| Non Ferrous (N) Compatibility | No |
| Shank Type | Weldon |
| Grade | 0 |
| Chamfer Width | 0.0390 in |
| Measurement System | Fractional Inch |
| Material - Machining | Cobalt |
| Finish - Machining | Bright (Uncoated) |
| Shank Type - Machining | Weldon Flat |
| Drilling Tool Configuration | Individual |
| Coolant Fed | Non-Coolant Through |
| Primary Material Application | Steel |
| Spiral Direction | Right Hand |
| Secondary Material Application | Nickel, Titanium |
| Country of Origin (subject to change) | Israel |
| Package Quantity | 1 |
End Mill, 1.0000 in. Milling Dia., 620V, Widia, Mfr#: 620V25088
$115.99
Free shipping will be applied on orders over $50
Corner Chamfer End Mill, 1 in Milling Dia., Cobalt, Bright (Uncoated), Non-Coolant Through, Weldon Flat, Fractional Inch, 0.0390 in, 2 in
Out of stock
