| Property | Value |
|---|---|
| Item | Digital Temperature Controller |
| Digital/Analog | Digital |
| Description/Special Features | Dual Loop or Single Loop/Alarm Output Control, RS-485 Modbus(R) Communication, Universal Transmitter or Temperature Sensor Inputs |
| Sensor Type | Platinum RTD, Thermocouple Types K, J, T, E, N, R, S, B, L, U, TXK |
| Input Voltage | 24V DC |
| Switch Function | 0 to 10 VDC (Output 1), 3 A @ 250 VAC Resistive (Output 2) |
| Output | (1) Linear Voltage and (1) Relay |
| Temp. Range | 32 Degrees to 122 Degrees F |
| Control Mode | PID |
| Amps | 3A |
| Power Consumption | 3 W |
| Series | Series SCD |
| Standards | CE, cULus, RoHS |
| Length | 90.06 mm |
| Width | 25.4 mm |
| Depth | 57.15 mm |
| Inputs | Thermocouple, RTD, DC linear voltage, and DC currents. |
| Memory Backup | Non-volatile. |
| Agency Approvals | CE, cULus. |
| Control Output Ratings | Relay: 3 A @ 250 VAC resistive, Voltage pulse: 12 VDC, max. output current: 40 mA, Current: 4 to 20 mA output, Linear voltage: 0 to 10 VDC. |
| Communication | RS-485 Modbus® A-5-11/RTU communication protocol. |
| Operating Temperature | 32 to 122?F (0 to 50?C). |
| Country of Origin (subject to change) | China |
| Package Quantity | 1 |
Digital Temperature Controller, 90.06mm L, DWYER INSTRUMENTS, Mfr# SCD-2063
$117.99
Free shipping will be applied on orders over $50
Digital Temperature Controller, Digital, Platinum RTD, Thermocouple Types K, J, T, E, N, R, S, B, L, U, TXK Sensor Type, Input Voltage 24V DC, Switch Function 0 to 10 VDC (Output 1), 3 A @ 250 VAC Resistive (Output 2), Output (1) Linear Voltage and (1) Relay, Temp. Range 32 Degrees to 122 Degrees F, Control Mode PID, 3A Amps, Length 90.06 mm, Width 25.4 mm, Depth 57.15 mm
Out of stock
