| Property | Value |
|---|---|
| Item | DC Gearmotor |
| Gearmotor Voltage | 90V DC |
| Gearmotor Type | DC Gearmotor |
| Max. Torque | 822 in-lb |
| Gearmotor Shaft Type | Single |
| Gearmotor Shaft Orientation | Parallel |
| Nameplate RPM | 34 RPM |
| Gearmotor Enclosure | Totally Enclosed Fan-Cooled |
| Gearmotor Rotation | CW/CCW |
| Length Less Shaft | 14 in |
| Gearmotor Mounting Position | All Angle |
| Full Load Amps | 5 A |
| Standards | C-UL Recognized, UL Recognized |
| Input HP | 1/2 |
| Voltage | 90VDC |
| Gear Case | Die Cast Aluminum |
| Gear Material | Hardened Steel |
| Replacement Brushes | 6YHY9 |
| Max. Ambient Temp. | 40 Degrees C |
| RPM Range | 31 to 50 |
| Motor Type | Permanent Magnet DC |
| Gear Type | Helical, Spur |
| Shaft Orientation | Parallel |
| Seals | Lip Type on Input and Output Shaft |
| Mounting | All Position |
| Gear Ratio | 50:1 |
| Lubrication | Permanent Heavy Fluid Gear Oil |
| Rear Shaft Encoder/Pulse Generator Mounting | No |
| Reversible Shaft Output | No |
| Rotation | CW/CCW |
| Shaft Length (Dimension V) | 1-1/2 |
DC Gearmotor, 822.0 in-lb Max. Torque, 34 RPM Nameplate RPM, 90V DC Voltage, DAYTON, Mfr# 6Z414
$1059.99
Free shipping will be applied on orders over $50
DC Gearmotor, Shaft Orientation Parallel, Motor Enclosure Totally Enclosed Fan-Cooled, Operating Voltage 90V DC, Motor Type Permanent Magnet DC, Nameplate Speed 34 RPM, Maximum Torque 822 in-lb, Overhung Load Capacity 325 ft-lb, Rotation CW/CCW, Output Shaft Height 3 in, Mounting Orientation Any Angle, Gear Ratio 50:1, Input Horsepower 1/2 hp, Output Shaft Diameter 3/4 in, Bearing Type Ball on Motor, Heavy Duty Ball and Thrust Balls on Case
Out of stock
