| Property | Value |
|---|---|
| Item | DC Gearmotor |
| Gearmotor Voltage | 90V DC |
| Gearmotor Type | DC Gearmotor |
| Max. Torque | 710 in-lb |
| Gearmotor Shaft Type | Single |
| Gearmotor Shaft Orientation | Parallel |
| Nameplate RPM | 6.5 RPM |
| Gearmotor Enclosure | Totally Enclosed Nonventilated |
| Gearmotor Rotation | CW/CCW |
| Length Less Shaft | 12.5 in |
| Gearmotor Mounting Position | All Angle |
| Full Load Amps | 1 A |
| Standards | C-UL Recognized, UL Recognized |
| Input HP | 1/6 |
| Dimension H | 4.67 |
DC Gearmotor, 710 in-lb Max. Torque, 6.5 RPM Nameplate RPM, 90V DC Voltage, DAYTON, Mfr# 2H592
$677.99
Free shipping will be applied on orders over $50
DC Gearmotor, Shaft Orientation Parallel, Motor Enclosure Totally Enclosed Nonventilated, Operating Voltage 90V DC, Motor Type Permanent Magnet DC, Nameplate Speed 6.5 RPM, Maximum Torque 710 in-lb, Overhung Load Capacity 900 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Gear Ratio 276:1, Input Horsepower 1/6 hp, Output Shaft Diameter 3/4 in, Bearing Type Ball on Motor, Needle Throughout
Out of stock
