| Property | Value |
|---|---|
| Item | DC Gearmotor |
| Gearmotor Voltage | 90V DC |
| Gearmotor Type | DC Gearmotor |
| Max. Torque | 280 in-lb |
| Gearmotor Shaft Type | Single |
| Gearmotor Shaft Orientation | Parallel |
| Nameplate RPM | 22 RPM |
| Gearmotor Enclosure | Totally Enclosed Nonventilated |
| Gearmotor Rotation | CW/CCW |
| Length Less Shaft | 10.13 in |
| Gearmotor Mounting Position | All Angle |
| Full Load Amps | 1.41 A |
| Standards | C-UL Recognized, UL Recognized |
| Input HP | 1/8 |
| Mounting | All Position |
| Shaft Orientation | Parallel |
| Shaft Length (Dimension V) | 1 1/2 in |
| Housing Material | Aluminum |
| Gear Case | Die Cast Aluminum |
| Gear Material | Hardened Steel |
| Seals | On Input and Output Shaft |
| Thermal Protection | None |
| Enclosure | TENV |
| Overhung Load | 150 lb |
| Replacement Brushes | 6YHY6 |
| Motor Type | Permanent Magnet DC |
| Shaft Dia. (Dimension U) | 5/8 in |
| Bearings | Ball on Motor, Needle Roller and Thrust Balls on Case |
| Brushes | Externally Replaceable |
| Lubrication | Permanent Heavy Fluid Gear Oil |
| Rear Shaft Encoder/Pulse Generator Mounting | Yes |
| RPM Range | 16 to 30 |
| Max. Ambient Temp. | 40 Degrees C |
| Tachometer Feedback | Yes |
| Voltage | 90VDC |
| Reversible Shaft Output | No |
| Overall Length | 11.63 in |
| Rotation | CW/CCW |
| Gear Ratio | 82:1 |
| Mounting Orientation | Any Angle |
| Full Load Current | 1.41 A |
| Seal Type | Lip Type on Input and Output Shaft |
| Operating Voltage | 90V DC |
| Motor Enclosure | Totally Enclosed Nonventilated |
| Bearing Type | Ball on Motor, Needle Roller and Thrust Balls on Case |
| Output Shaft Diameter | 5/8 in |
| Output Shaft Length | 1 1/2 in |
| Input Horsepower | 1/8 hp |
| Replaceable Motor Brushes | Yes |
| Maximum Ambient Temperature | 40 Degrees C |
| Overhung Load Capacity | 150 ft-lb |
| Nameplate Speed | 22 RPM |
| Maximum Torque | 280 in-lb |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
DC Gearmotor, 280.0 in-lb Max. Torque, 22 RPM Nameplate RPM, 90V DC Voltage, Dayton, Mfr#: 4Z130
$434.53
Free shipping will be applied on orders over $50
DC Gearmotor, Shaft Orientation Parallel, Motor Enclosure Totally Enclosed Nonventilated, Operating Voltage 90V DC, Motor Type Permanent Magnet DC, Nameplate Speed 22 RPM, Maximum Torque 280 in-lb, Overhung Load Capacity 150 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Gear Ratio 82:1, Input Horsepower 1/8 hp, Output Shaft Diameter 5/8 in, Bearing Type Ball on Motor, Needle Roller and Thrust Balls on Case
Out of stock
