| Property | Value |
|---|---|
| Item | General Purpose Motor |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Type | Rigid Base |
| HP | 1 1/2 |
| RPM Range | 1,701-1,800 |
| Voltage | 115/208-230V AC |
| Frame | 56H |
| Motor Thermal Protection | Auto |
| Motor Service Factor | 1.15 |
| No. of Speeds | 1 |
| Voltage Compatibility | 115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC |
| Motor Application | General Application |
| Nameplate RPM | 1,725 |
| Motor Frame Material | Rolled Steel |
| Motor Mounting Position | Horizontal |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Design | Capacitor-Start/Run |
| Standards | UL (E37403) |
| Length Less Shaft | 11 3/16 in |
| Motor Efficiency Group | Premium Efficient |
| Green Environmental Attribute | Product Contributes To Reducing Energy Consumption |
| RPM Group | 1701-1800 |
| Frame Material | Rolled steel |
| Nominal Efficiency | 83.8 % |
| Green Certification or Other Recognition | Energy Aware |
| Phase | Single |
| Max. Ambient Temp. | 104 Degrees F |
| Duty | Continuous |
| Motor Bearings | Ball |
| Overall Length | 13 1/8 in |
| Inverter Rated | No |
| Manufacturers Warranty Length | 1 yr |
| Full Load Amps | 12.6/6.9-6.3 A |
| Hz | 60 Hz |
| Includes | Start/Run Capacitors |
| Shaft Dia. | 5/8 in |
| Ins. Class | B |
| Shaft Length | 1 7/8 in |
| Duty Cycle | Continuous |
| Capacitor Required | Yes |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
Capacitor-Start/Run General Purpose Motor, 1 1/2 HP, 115/208-230V AC Voltage, 56H Frame, Dayton, Mfr#: 119170.00
$652,99
Free shipping will be applied on orders over $50
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 1/2 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 12.6/6.9-6.3 A, 56H Frame, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 104 Degrees F, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Dripproof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base, Motor Mounting Position Horizontal, Inverter Rated No
