| Property | Value |
|---|---|
| Item | Precision Ball Nut |
| Type | Non-Preloaded |
| Ball Screw Dia. | 0.631 in |
| Lead | 0.2 in |
| Number of Starts | 1 |
| Thread Direction | Right Hand |
| Dynamic Load Capacity | 800 lb |
| Static Load Capacity | 6,150 lb |
| Material | Carbon Steel |
| Dimension B | 0.787 in |
| Dynamic Load Capacity (Lb.) | 800 |
| Static Load Capacity (Lb.) | 6150 |
| Direction | Right Hand |
| Dimension D | 15/16-16 UN |
| For Use With End Blocks | 2LGL2 |
| Dimension F | 0.5 in |
| Lead (In.) | 0.2 |
| Ball Circle Dia. (In.) | 0.631 |
| Dimension E | 1.71 in |
| Dimension C | 1.125 in |
| Dimension A | 0.8 in |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
Ball Nut, Ball Circle Dia 0.631 In, THOMSON, Mfr# 8106-448-009
$91.89
Free shipping will be applied on orders over $50
Precision Ball Nut, Non-Preloaded, Ball Circle Dia 0.631 In, Lead 0.200 In, Right Hand Direction, Dynamic Load Capacity 800 Lb, Static Load Capacity 6,150 Lb, Number of Starts 1, Carbon Steel Material, For Use With End Blocks 2LGL2
Out of stock
