| Property | Value |
|---|---|
| Item | AC Gearmotor |
| Gearmotor Voltage | 115/230V AC |
| Gearmotor Phase | 1 |
| Gearmotor Type | AC Gearmotor |
| Max. Torque | 710 in-lb |
| Gearmotor Shaft Type | Single |
| Gearmotor Shaft Orientation | Parallel |
| Nameplate RPM | 1.2 RPM |
| Gearmotor Enclosure | Totally Enclosed Nonventilated |
| Gearmotor Rotation | CW/CCW |
| Gearmotor Brake Type | None |
| Length Less Shaft | 9.94 in |
| Gearmotor Mounting Position | All Angle |
| Full Load Amps | 0.36/0.21 |
| Standards | C-UL Recognized, UL Recognized |
| Input HP | 1/58 hp |
| Mounting | All Position |
| Phase | Single |
| Brake | Adaptable to 5X400 |
| Hz | 60/50 Hz |
| Shaft Dia. (Dimension U) | 3/4 in |
| Gear Type | Helical (1st Stage), Spur (Subsequent Stages) |
| Rotation | CW/CCW |
| Overhung Load | 900 lb |
| Capacitor Required | Yes |
| Gear Ratio | 1424:1 |
| Bearings | Ball on Motor, Needle Throughout with Thrust Balls on Case |
| Gears | 1st Stage Helical, AGMA Class 9, Hardened Steel, Subsequent Stages Spur |
| Dimension A | 0.36/0.21 in |
| Motor Type | Permanent Split Capacitor |
| Shaft Length (Dimension V) | 1.88 |
AC Gearmotor, 710.0 in-lb Max. Torque, 1.2 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase, DAYTON, Mfr# 2H618
$932.99
Free shipping will be applied on orders over $50
AC Gearmotor, Number of Output Shafts 1, Motor Type Permanent Split Capacitor, Motor Enclosure Totally Enclosed Nonventilated, Nameplate Speed 1.2 RPM, Maximum Torque 710 in-lb, Overhung Load Capacity 900 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Operating Voltage 115/230V AC, Inverter Rated Yes, Gear Ratio 1424:1, Brake Type None, Shaft Orientation Parallel, AGMA Gear Class Class 9
Out of stock
