| Property | Value |
|---|---|
| Item | AC Gearmotor |
| Gearmotor Voltage | 115/230V AC |
| Gearmotor Phase | 1 |
| Gearmotor Type | AC Gearmotor |
| Max. Torque | 500 in-lb |
| Gearmotor Shaft Type | Single |
| Gearmotor Shaft Orientation | Parallel |
| Nameplate RPM | 20 RPM |
| Gearmotor Enclosure | Totally Enclosed Fan-Cooled |
| Gearmotor Rotation | CW/CCW |
| Gearmotor Brake Type | None |
| Length Less Shaft | 10 in |
| Gearmotor Mounting Position | All Angle |
| Full Load Amps | 2.05/1.05 |
| Keyway Size Type | 0.18 sq in x 1 in |
| Standards | C-UL Recognized, UL Recognized |
| Input HP | 1/5 hp |
| RPM @ 50 Hz | 17 |
| Reversible Shaft Output | No |
| Lubrication | Grease Filled |
| Overhung Load | 400 lb |
| Hz | 60/50 Hz |
| Shaft Length (Dimension V) | 1.38 |
AC Gearmotor, 500.0 in-lb Max. Torque, 20 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase, DAYTON, Mfr# 1LPX2
$714.99
Free shipping will be applied on orders over $50
AC Gearmotor, Number of Output Shafts 1, Motor Type Permanent Split Capacitor, Motor Enclosure Totally Enclosed Fan-Cooled, Nameplate Speed 20 RPM, Maximum Torque 500 in-lb, Overhung Load Capacity 400 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Operating Voltage 115/230V AC, Inverter Rated Yes, Gear Ratio 80:1, Brake Type None, Shaft Orientation Parallel, Motor Insulation Class B
Out of stock
